Digital Temp. Controller
The LCD display is an affordable temperature and process controller with advanced functionality including profiling and datalogging options. Designed to improve user efficiency many features are integrated to reduce commissioning time, simplify operation and minimise maintenance downtime. The LCD screen on DCP200 displays real-text messages, removing ambiguity that can be caused by mnemonic codes on LED displays used in many products. Information is displayed in a logical format to be easily understood, hence reducing the risk of errors.
Features:
- Dryers.
- Semiconductor packaging / testing.
- Plastic processing.
- Packaging machinery.
- Painting and coating.
- Climatic chambers.
- Easy to configure: Two different configuration levels provide easy access to parameters.
- A 4-digit security code prevents unauthorized changes.
- Parameters can also be hidden to the user to prevent mis-configuration of the unit.
- Higher display: 4 digits dedicated to display the PV.
- In configuration mode, this display indicates the value of the parameter or the patameter selected.
- Lower display: 4 digits dedicated to display the SP
- In configuration mode, indicates the name of the parameter.
- Bargraph: A 10 green LEDs bargraph indicates the value of the output in percentage.
| Model No. | DC1040 |
| Size | 96 x 96 mm |
| Control Type | On-Off |
| Input Type | Thermocouple, Current (mA), RTD |
| Control output Type | Analog (mA/mV), Relay, SSR |
| Brand | Honeywell |
| Controller Type | PID |
| Display Type | 4 Digit/7 Segment |
| Mounting Type | Panel |
| Voltage | 100-240 VAC |
| Alarm | 2 alarms |
| Input Sampling Time | 250 ms |
| Input Resolution | 14 bit (each) |
| Accuracy | +- 0.5%FS |
| Power Supply | AC 85~265V,50Hz |
